Robust Construction & Durability:

Made from 304 series stainless steel for fire-rated applications

Precision bearings ensure smooth and reliable operation

Wide Variety of Options:

Available in a variety of finishes to suit different design aesthetics

Available for fire-rated, non-fire-rated, and power transfer offset pivots

Enhanced Performance & Flexibility:

Essential for door heights over 7'0" and for every additional 2'6" as needed

Provides additional support for doors weighing over the pivot set limit; use one additional pivot for every extra 100 pounds

Handed for both left-hand (LH) and right-hand (RH) installations

Material: Made from high-strength 304 series stainless steel

Recommended Door Thickness: Minimum 1 ¾" with 1/8" bevel in 2"

Handed: Available in LH or RH configurations

Certifications:

Meets ANSI/BHMA A156.4 standards for performance and durability

UL 10C Listed for 3-hour fire rating, ensuring safety and compliance

Models:

7230F-7237F INT: ¾" offset intermediate pivot for use with 7230F and 7237F offset pivots; fire-rated

7230FPT-7237FPT INT: ¾" offset power transfer intermediate pivot for use with 7230F and 7237F offset pivots; fire-rated

View available finishes to suite with your LCN, Schlage, or Von Duprin hardware.

Finishes:

Bright Stainless (US32): BHMA 629

Satin Stainless (US32D): BHMA 630

Matte Black (BLK): BHMA 631

Bright Brass (US3): BHMA 632

Satin Bronze (US10): BHMA 639

Aged Bronze (643e/716)

Aluminum Painted (SP28): BHMA 689

Bronze Painted (SP10): BHMA 691

Dark Bronze Painted (SP313/US10BE): BHMA 695

Brass Painted (SP4): BHMA 706
