Durable Construction: Made from .050" thick material such as brass, stainless steel, and aluminum to ensure long-lasting performance in high-traffic areas.

Flexible Installation: Plates are available in a variety of sizes and can be easily mounted on wood, metal, or aluminum doors.

Corrosion Resistance: Stainless steel options (300 series) provide excellent resistance to rust and corrosion, making them perfect for both indoor and outdoor use.

Customizable Sizing: Standard sizes include a range of widths and heights, with custom sizes available upon request.

Quality: Meets ANSI/BHMA A156.6 for superior quality and reliability in commercial applications.

Materials: Brass, Stainless steel (8300 Series) Aluminum

Mounting Hardware:

8200/8300 Push and Pull Plates:

Standard  #6 x 5/8” oval head screws

Optional Self-drilling Tek screws, Torx screws for added security

Pull and Push Plate Combos, See Catalog for Details.

Certifications: ANSI/BHMA A156.6

Additional Information:

Specify PR when ordering a set of plates for back-to-back mounting.

Plates are available with cutout for cylinder or thumb-turn; standard cutout is 2" from top and centered on plates up to 4" wide. For plates wider than 4", cutout is located 2" from outer edge, specify LH or RH. When pull location interferes with standard cutout location, a detail drawing should be furnished with the order.

Standard cutout is 1 1⁄4" for cylinder and 3⁄8" for thumb-turn

Specify CFC for cutout for cylinder or CFT for cutout for thumb-turn

8200 Push Plate: Standard flat push plate for high-traffic doors

8300 Pull Plate (Less Pull): Prepped for Ives pulls but can be customized for other pull models

8302 Pull Plate: Prepped with Ives 8102 pull for a standard pull and plate combination

8303, 8305, 8311 Pull Plates: Available with Ives pulls 8103, 8105, and 8111 respectively

Sizes & Dimensions:

8200 Push Plates: Available in 3” x 12”, 3 1/2” x 15”, 4” x 16”, 6” x 16”, and 8” x 16”

8300 Pull Plates: Prepped for pulls with 5-1/4", 6”, 8”, 10”, or 12” center-to-center spacing

8302 3/4" Round Pull with Plate: Available in 3 1/2” x 15”, 4” x 16”, 6” x 16” or 6", 8", 10" center-to-center spacing

8303 1" Round Pull with Plate: Available in 3 1/2” x 15”, 4” x 16”, 6” x 16” or 6", 8", 10" center-to-center spacing

8305 1" wide and 1/2" diameter Pull with Plate: Available in 3 1/2” x 15”, 4” x 16”, 6” x 16” or  8", 10" center-to-center spacing

8311 1" Round Base, Tapered Pull with Plate: Available in 3 1/2” x 15”, 4” x 16”, 6” x 16” or 5-1/4" center-to-center spacing

Bright Brass (US3): BHMA 605

Satin Brass (US4): BHMA 606

Satin Bronze (US10): BHMA 612

Oil Rubbed Bronze (US10B): BHMA 613

Satin Nickel (US15): BHMA 619

Bright Chrome (US26): BHMA 625

Satin Chrome (US26D): BHMA 626

Satin Chrome Antimicrobial (US26D-AM): BHMA 626-AM

Clear Anodized Aluminum (US28): BHMA 628

Satin Stainless (US32D): BHMA 630

Satin Stainless Antimicrobial (US32D-AM): BHMA 630-AM

Matte Black (BLK): BHMA 631

Dark Bronze Powder Coat (SP313/US10BE): BHMA 695
